Product Description
Keyence LJ-X8060
The Keyence LJ-X8060 is a high-performance 2D/3D laser profile sensor head designed for precise, non-contact measurement and inspection. As part of the LJ-X8000 Series, it utilizes a stable blue laser and advanced processing algorithms to deliver exceptional accuracy and reliability, even on challenging surfaces with varying reflectivity. This sensor head is engineered for high-speed applications, enabling rapid inline profiling, defect detection, and quality control in demanding manufacturing environments. Its robust, IP67-rated housing ensures dependable performance in harsh industrial conditions, making it an ideal solution for automation and process control.
Technical Specifications:
- Measurement Range (Z-axis): 32 mm (Reference distance: 60 mm)
- Measurement Range (X-axis): 28 mm (Near) / 32 mm (Center) / 36 mm (Far)
- Light Source: Blue semiconductor laser, Wavelength 405 nm
- Repeatability (Z-axis): 0.2 µm
- Maximum Sampling Speed: 16 kHz (64 µs)
- Enclosure Rating: IP67
Keyence LJ-X8060
Discover the Keyence LJ-X8060, a high-speed 2D/3D laser profiler head for accurate inline inspection and measurement. Features a stable blue laser, exceptional repeatability, and a rugged IP67 rating for reliable industrial use.
