Product Description

Murr 555280

The Murr 555280 from Murrelektronik is a high-quality M12 field-wireable connector designed for creating custom-length cable assemblies directly on-site. This straight, 4-pole male connector features user-friendly screw terminals, allowing for quick and secure wire termination without the need for specialized tools. Its rugged zinc die-cast housing and IP67 rating ensure reliable performance and protection against dust and water ingress, making it an ideal solution for demanding industrial automation, sensor, and actuator applications.

Technical Specifications:

  • Part Number: 555280

  • Connector Type: M12 Male, Straight (0°)

  • Number of Poles: 4

  • Termination: Screw terminals

  • Operating Voltage: max. 250 V AC/DC

  • Operating Current: max. 4 A per contact

  • Cable Outlet Diameter: 4 – 6 mm

  • Protection Class: IP67 (when mounted and tightened)

Murr 555280 Description

Murr 555280

Purchase the Murr 555280, a reliable Murrelektronik M12 4-pole male field-wireable connector. Features a straight design with secure screw terminals and IP67 protection for industrial environments.
