Product Description
Norgren VCB22A517D-C5213A
The Norgren VCB22A517D-C5213A is a direct-acting 2/2 way normally closed solenoid valve from the VCB22 series. It is designed for general-purpose fluid control applications. This valve features a robust brass body and NBR (Nitrile Rubber) seals, making it suitable for use with media such as compressed air, inert gases, water, and light oils (compatibility with NBR should always be verified for specific applications). The G1/4 port connections and compact design facilitate easy integration into various systems. This particular model is equipped with the C5213A solenoid coil, which typically operates at 24V DC.
Technical Specifications:
- Valve Type: 2/2 Normally Closed (NC) Solenoid Valve
- Series: VCB22
- Actuation: Direct Acting
- Port Size: G1/4
- Orifice Diameter: 5 mm
- Body Material: Brass
- Seal Material: NBR (Nitrile Rubber)
- Operating Pressure Range: 0 – 10 bar (with DC coil)
- Fluid Temperature Range: -10°C to +80°C (with NBR seals)
- Ambient Temperature Range: Dependent on coil, typically up to +50°C or +65°C
- Coil Part Number: C5213A
- Coil Voltage: 24V DC
- Coil Power: 11W
- Flow Factor (Kv): Approximately 0.5 m³/h
- Media Compatibility: Compressed air, inert gases, water, light oil (User to verify NBR compatibility with specific media)
- Electrical Connection: Typically via DIN connector (connector to be ordered separately)
Norgren VCB22A517D-C5213A
Model：Norgren VCB22A517D-C5213A
| Brand | Norgren |
|---|---|
| Model | VCB22A517D-C5213A |
| Part No. | Norgren VCB22A517D-C5213A |
| Category | Hydraulic valves |
