Product Description

Norgren VCB22B411A-AB213J

The Norgren VCB22B411A-AB213J is a high-efficiency coalescing filter, part of the Excelon® Plus series, engineered for exceptional removal of oil aerosols, water, and sub-micron particulate matter from compressed air systems. It plays a crucial role in protecting sensitive downstream equipment, enhancing product quality in manufacturing processes, and minimizing operational costs by delivering exceptionally clean, oil-free air. This particular configuration is equipped with G1/4 ports, a high-performance 0.01 µm filtration element, a robust polycarbonate bowl with a protective guard, and a manual drain mechanism for ease of maintenance.

Technical Specifications:

  • Series: Excelon® Plus VCB22
  • Port Size: G1/4 (ISO G/PTF option G)
  • Filtration Element Grade: 0.01 µm
  • Particle Removal: Down to 0.01 micron
  • Maximum Remaining Oil Content: <0.01 mg/m³ (at +21°C with an inlet oil concentration of 10 mg/m³)
  • Bowl Material: Polycarbonate bowl with steel guard
  • Drain Type: Manual drain
  • Maximum Inlet Pressure (Polycarbonate Bowl): 10 bar (145 psi)
  • Operating Temperature (Polycarbonate Bowl, NBR Seals): -20°C to +65°C (-4°F to +149°F)
  • Seals Material: Nitrile (NBR)
  • Typical Flow (0.01µm element at 6.3 bar inlet, 0.35 bar ΔP): 7 dm³/s (15 scfm)
  • Fluid: Compressed air

Norgren VCB22B411A-AB213J

Model:Norgren VCB22B411A-AB213J
