Product Description

Norgren VCB22D317A-AD219J

The Norgren VCB22D317A-AD219J is a high-performance 2/2 normally closed solenoid-operated poppet valve, part of the VCB series. It is engineered for reliable control of compressed air or other inert gases in a variety of industrial automation and pneumatic applications. This direct-acting valve features G1/4 port connections and is actuated by a 24V DC solenoid. The robust poppet design ensures high flow rates, rapid response times, and a long operational lifespan, making it a dependable component for sophisticated control systems. This model typically includes a DIN connector for convenient and secure electrical installation.

Technical Specifications:

Brand: Norgren (IMI Precision Engineering)
Series: VCB
Model: VCB22D317A-AD219J
Type: Solenoid Operated Poppet Valve
Function: 2/2 Normally Closed (NC)
Port Connections: G1/4
Operating Principle: Direct Acting Poppet
Solenoid Voltage: 24V DC
Nominal Power Consumption: Typically 2W (associated with ‘317A’ coil designation)
Electrical Connection: DIN Connector (e.g., DIN 43650 Form A or B, specific type may vary with ‘AD219J’ suffix)
Operating Pressure Range: 0 – 7 bar (0 – 101.5 psi)
Media: Filtered compressed air (lubricated or non-lubricated), inert gases
Body Material: Aluminium (Typical for VCB series)
Seal Material: NBR (Nitrile) (Standard for VCB series)
Typical Ambient/Media Temperature Range: -10°C to +80°C (14°F to 176°F) (dependent on solenoid and specific application conditions)
