Product Description
Norgren VCB22B511A-AB213L
The Norgren VCB22B511A-AB213L is a high-performance 2/2 way normally closed angle seat solenoid valve from the VCB22 series, engineered for reliable control of process fluids. Constructed with a durable stainless steel (AISI 316L) body and PTFE seals, this piston-actuated valve is suitable for demanding industrial applications. It features a G1/2 port size and is operated by a 24V DC solenoid with an M12 connector, providing IP65 protection. This valve is designed for handling various media including air, gas, liquids, and steam within specified pressure and temperature limits.
Technical Specifications:
- Product Series: VCB22
- Valve Type: 2/2 Angle Seat Solenoid Valve
- Function: Normally Closed (NC)
- Port Connection: G1/2
- Body Material: Stainless Steel (AISI 316L)
- Seal Material: PTFE
- Actuator Diameter: 50mm
- Solenoid Voltage: 24V DC
- Solenoid Power Consumption: 2.5W
- Solenoid Electrical Connection: M12 Connector
- IP Rating (Solenoid): IP65 (with connector properly assembled)
- Maximum Operating Pressure (Air/Gas/Liquids): 16 bar
- Maximum Operating Pressure (Steam): 10 bar (up to 180°C)
- Fluid Temperature Range: -20°C to +180°C (with PTFE seals)
- Ambient Temperature Range (Solenoid): -10°C to +50°C
- Flow Coefficient (Kv): 4.8 m³/h
Norgren VCB22B511A-AB213L
Model：Norgren VCB22B511A-AB213L
| Brand | Norgren |
|---|---|
| Model | VCB22B511A-AB213L |
| Part No. | Norgren VCB22B511A-AB213L |
| Category | Hydraulic valves |
