Product Description
Norgren VCB22D511A-AD213L Coalescing Filter
The Norgren VCB22D511A-AD213L is a high-efficiency coalescing filter from the renowned Excelon Plus series, engineered for exceptional compressed air purification. It excels at removing oil aerosols, water, and sub-micron particulate matter down to 0.01 micron, ensuring the protection and longevity of downstream pneumatic components and critical processes. This unit is equipped with a durable polycarbonate bowl with a protective steel guard, allowing for easy visual inspection of condensate levels. It features an integrated electric automatic drain (Norgren AD213L, 24V DC, M12 connector) for reliable and maintenance-free condensate removal, making it ideal for applications demanding high-purity compressed air and operational efficiency.
Technical Specifications:
- Product Type: Coalescing Filter (Boxed Unit)
- Series: Excelon Plus
- Port Size: G1/4 ISO G parallel thread
- Filtration Grade: 0.01 µm (removes oil aerosols and sub-micron particles)
- Bowl Material: Polycarbonate
- Bowl Guard: Steel
- Drain Type: Electric Automatic Drain (Norgren AD213L)
- Drain Operating Voltage: 24V DC
- Drain Electrical Connection: M12 4-pin A-coded connector
- Operating Pressure Range: 0.3 to 10 bar (4.35 to 145 psi)
- Operating Temperature Range: -20°C to +60°C (-4°F to +140°F)
- Seal Material: NBR (Nitrile)
- Nominal Flow Rate: 6 dm³/s (12.7 scfm) at 6.3 bar inlet pressure and 0.35 bar pressure drop
- Fluid Compatibility: Compressed Air
- Body Material: Aluminium
Norgren VCB22D511A-AD213L
Model：Norgren VCB22D511A-AD213L
| Brand | Norgren |
|---|---|
| Model | VCB22D511A-AD213L |
| Part No. | Norgren VCB22D511A-AD213L |
| Category | Hydraulic valves |
