Product Description
Norgren VCB22B417A-AB219J
The Norgren VCB22B417A-AB219J is a high-quality, direct-acting 2/2-way solenoid valve from the Buschjost VCB22 series. Engineered for reliability, this valve is designed to control the flow of neutral gaseous and liquid fluids. It features a robust brass body and durable FPM (Fluorocarbon rubber) seals, ensuring compatibility with a range of media and operating conditions. As a normally closed valve, it remains shut until energized, providing fail-safe operation in many applications. The VCB22B417A-AB219J is equipped with a 24V DC coil and utilizes a standard DIN EN 175301-803 Form B electrical connection for straightforward installation and system integration. Its compact design and precise flow control make it suitable for various industrial applications requiring dependable fluid management.
Technical Specifications:
- Valve Type: 2/2-way Solenoid Valve
- Series: Buschjost VCB22
- Actuation: Direct Acting
- Function: Normally Closed (NC)
- Port Connection: G1/8
- Body Material: Brass
- Seal Material: FPM (Fluorocarbon rubber)
- Orifice Size: 1.7 mm
- Kv Value: 0.09 m³/h
- Operating Pressure Range: 0 – 25 bar
- Fluid Temperature Range: -10°C to +100°C
- Ambient Temperature Range: -10°C to +50°C
- Voltage: 24V DC
- Power Consumption: 8W
- Electrical Connection: DIN EN 175301-803 Form B (Industrial Standard)
- IP Rating: IP65 (with mating connector correctly installed)
- Media Compatibility: Neutral gaseous and liquid fluids
Norgren VCB22B417A-AB219J
Model：Norgren VCB22B417A-AB219J
