Product Description
Norgren VCB22B511A-AB213J
The Norgren VCB22B511A-AB213J is a 2/2-way externally controlled coaxial valve, part of the proven VCB22 series. These valves are designed for reliable control of neutral gaseous and liquid fluids, and are also suitable for vacuum applications. The VCB22B511A-AB213J features a normally closed operation, brass body construction for durability, and NBR seals for compatibility with a wide range of media. Its G1/2 port connections and 24V DC solenoid operator make it a versatile choice for various industrial automation tasks requiring high flow rates and robust performance in a compact footprint.
Technical Specifications:
- Valve Type: Coaxial Valve
- Function: 2/2 Way, Normally Closed (NC)
- Port Size: G1/2 (ISO G/BSPP)
- Body Material: Brass
- Seal Material: NBR (Nitrile Rubber)
- Solenoid Operator Voltage: 24V DC (Coil P/N: AB213J)
- Operating Pressure Range: 0 – 40 bar (0 – 580 psi)
- Media: Neutral gaseous and liquid fluids, vacuum
- Flow Direction: Reversible
- Orifice Size: 15 mm
- Kv Value: 4.8 m³/h
- Ambient Temperature Range: -10°C to +50°C (14°F to 122°F)
- Fluid Temperature Range: -10°C to +80°C (14°F to 176°F) (with NBR seals)
- Mounting Position: Optional
Norgren VCB22B511A-AB213J
Model：Norgren VCB22B511A-AB213J
