Norgren VCB22B517A-AB219L
The Norgren VCB22B517A-AB219L is a high-performance 2/2-way angle seat valve designed for robust process control in various industrial applications. It features a durable bronze body and PTFE seals, ensuring compatibility with a wide range of media including steam, water, air, and other neutral or aggressive fluids (subject to compatibility checks). This normally closed valve is actuated by a 50mm polyamide actuator and controlled by an integrated 24V DC solenoid pilot valve (Norgren’s AB219L specification), which includes an LED indicator for operational status. With G3/4 (BSPP) threaded connections, it offers reliable sealing and easy installation. The VCB series is known for its high flow rates and long service life, making it suitable for demanding on/off applications.
Technical Specifications:
- Valve Type: 2/2 Way Angle Seat Valve
- Series: VCB
- Model: VCB22B517A-AB219L
- Port Size: G3/4 (DN20)
- Connection Type: Female Threaded G (BSPP – ISO 228/1)
- Body Material: Bronze
- Seal Material: PTFE
- Actuator Type: Piston Actuator, Polyamide (PA)
- Actuator Size: 50mm diameter
- Function: Normally Closed (NC) – Spring Return, Air to Open
- Control Type: Solenoid Pilot Operated
- Pilot Solenoid: Integrated, Norgren AB219L specification (includes pilot valve, coil, connector, and LED)
- Pilot Solenoid Voltage: 24V DC
- Pilot Solenoid Electrical Connection: Typically DIN 43650 Form C connector (indicated by ’19’ in the code)
- Pilot Solenoid Indicator: LED (indicated by ‘L’ in the code)
- Fluid Media: Steam, water, air, neutral gases, oils, aggressive fluids (PTFE compatibility must be verified for specific fluid)
- Maximum Operating Pressure (Valve): Up to 16 bar (232 psi) for fluids; Up to 10 bar (145 psi) for steam (refer to specific Norgren datasheet for precise pressure/temperature ratings)
- Fluid Temperature Range: -10°C to +180°C (+14°F to +356°F) (limited by PTFE seals)
- Ambient Temperature Range (Actuator): -10°C to +60°C (+14°F to +140°F)
- Flow Coefficient (Kv): Approximately 9 m³/h
- Flow Direction: As indicated on valve body (typically fluid entry under the disc for NC valves)
