Product Description

Norgren VCB22C511A-AC213L

The Norgren VCB22C511A-AC213L is a high-performance 2/2 way solenoid operated angle seat valve, part of the VCB22 series. Engineered for reliability in demanding industrial applications, it features a durable bronze body and PTFE seals, ensuring compatibility with a broad spectrum of media such as steam, water, air, oil, and other aggressive fluids. This valve is configured as normally closed and is actuated by the AC213L solenoid coil, which operates on 230V AC and includes an integrated LED status indicator and VDR for electrical protection. The angle seat design promotes high flow rates and robust performance, making it an excellent choice for process control.

Technical Specifications:

Valve Type: 2/2 Way Solenoid Operated Angle Seat Valve
Series: VCB22
Model: VCB22C511A
Operation: Normally Closed (NC)
Port Size: G1 (1 inch BSPP)
Body Material: Bronze
Seal Material: PTFE
Solenoid Coil: AC213L
Coil Voltage: 230V AC, 50/60Hz
Coil Features: LED indicator, VDR (Voltage Dependent Resistor for surge suppression)
Coil Power Consumption: Inrush: 17 VA, Holding: 9 VA / 5W
IP Rating (Coil): IP65 (with appropriate connector)
Media Compatibility: Steam, water, air, oil, aggressive fluids
Maximum Operating Pressure (Fluids): Up to 16 bar (232 psi)
Maximum Operating Pressure (Steam): Up to 10 bar (145 psi)
Media Temperature Range: -10°C to +180°C (14°F to 356°F)
Ambient Temperature Range: -10°C to +60°C (14°F to 140°F) (dependent on media temperature and coil used)
Flow Direction: As indicated on valve body (typically under the seat for NC configuration)
