Product Description
Norgren VCB22C517A-AE213J
The Norgren VCB22C517A-AE213J is a high-quality 2/2 way normally closed direct acting solenoid valve from the VCB22 series. It is engineered for reliable performance in a wide range of industrial applications. Featuring a robust brass body and durable NBR (Nitrile Rubber) seals, this valve is suitable for controlling neutral gaseous and liquid fluids. Its direct acting design ensures dependable operation and a quick response time, even under zero pressure conditions. This model comes with a 230V AC (50/60Hz) coil for electrical actuation, making it a versatile component for automation and fluid control systems.
Technical Specifications:
- Valve Type: 2/2 Way Normally Closed, Direct Acting
- Series: VCB22
- Port Connection: G1/4 (BSPP)
- Orifice Size: 3.0 mm
- Body Material: Brass
- Seal Material: NBR (Nitrile Rubber)
- Coil P/N: AE213J
- Voltage: 230V AC, 50/60Hz
- Operating Pressure Range: 0 – 10 bar
- Media Temperature Range: -10°C to +80°C
- Ambient Temperature Range: -10°C to +50°C (for standard coil)
- Flow Factor (Kv): 0.25 m³/h
- Electrical Connection Interface: DIN 43650 Form A
- Protection Class: IP65 (when used with a correctly installed and appropriate connector)
Norgren VCB22C517A-AE213J
Model：Norgren VCB22C517A-AE213J
