Product Description

Norgren VCB22D517A-AD219J

The Norgren VCB22D517A-AD219J is a 2/2-way servo-assisted solenoid valve from the Buschjost VCB22 series. It is designed for normally closed operation, featuring a robust brass body and durable NBR (Nitrile Butadiene Rubber) seals, making it suitable for a variety of general-purpose fluid control applications. This valve is equipped with G1/2 port connections and is actuated by a 24V DC solenoid with a DIN EN 175301-803 Form A electrical connection.

Technical Specifications:

Valve Type: 2/2-way servo-assisted solenoid valve
Series: VCB22 (Buschjost)
Operation: Normally Closed (NC)
Body Material: Brass
Port Connection: G1/2 (ISO 228/1)
Seal Material: NBR (Nitrile Butadiene Rubber)
Solenoid Voltage: 24V DC
Solenoid Power: 8W
Solenoid System: 9500 series
Electrical Connection: DIN EN 175301-803 Form A (connector typically ordered separately)
Operating Pressure Range: 0.5 to 16 bar (7.25 to 232 psi)
Medium Temperature Range: -10°C to +80°C (+14°F to +176°F)
Ambient Temperature Range: -10°C to +50°C (+14°F to +122°F)
Flow Factor (Kv): Approximately 4.5 m³/h
Orifice Size: DN15
