Product Description
Omron NX-DA3203
The Omron NX-DA3203 is a high-speed Analog Output Unit designed for the Omron NX-series I/O system. This module provides two high-resolution analog output points, capable of delivering both voltage and current signals. With a rapid conversion time of just 10 µs per point, it is ideal for applications requiring precise and fast control of devices such as inverters, servo drives, and proportional valves. The NX-DA3203 seamlessly integrates into the Sysmac automation platform via an EtherCAT Coupler, enabling synchronized control and reliable performance in demanding industrial automation environments. Its versatility is enhanced by supporting a wide range of output signals, including 0-10V, ±10V, and 4-20mA, which can be configured per channel.
Technical Specifications:
- Number of Outputs: 2 points
- Output Signal Range (Voltage): 0 to 10 V, 1 to 5 V, 0 to 5 V, -10 to +10 V
- Output Signal Range (Current): 4 to 20 mA, 0 to 20 mA
- Resolution: 1/8000 (Full Scale)
- Conversion Time: 10 µs/point
- I/O Connection Method: Screwless clamp terminal block
Omron NX-DA3203
Discover the Omron NX-DA3203, a high-speed, 2-point analog output unit for the NX I/O system. It offers precise voltage and current outputs with a 10 µs conversion speed, perfect for advanced motion and process control applications within the Sysmac platform.
