Product Description
PARKER D1VW002CNJW4N91
The Parker D1VW002CNJW4N91 is a high-performance, direct-operated solenoid directional control valve from the renowned D1VW series. Designed for reliability and long service life, this valve provides precise control in a wide range of industrial hydraulic applications. Its compact, industry-standard NG06 (CETOP 03 / NFPA D03) mounting interface ensures easy integration into both new and existing systems. Featuring a robust body and proven solenoid technology, the D1VW series is engineered to handle demanding operational cycles, making it a trusted choice for machine tools, material handling, and mobile equipment.
Technical Specifications:
- Series: D1VW
- Mounting Pattern: NG06 / CETOP 03 / NFPA D03
- Spool Type: 002 (2-Position, 4-Way, Spring Offset)
- Maximum Operating Pressure: 350 bar (5075 PSI)
- Maximum Flow Rate: 80 l/min (21 GPM)
- Solenoid Voltage: 120V AC (60Hz) / 110V AC (50Hz)
- Electrical Connection: DIN 43650 A / ISO 4400
- Seal Material: NBR (Nitrile)
PARKER D1VW002CNJW4N91
Shop the Parker D1VW002CNJW4N91, a high-performance NG06 / D03 solenoid-operated directional control valve. This 2-position, 4-way hydraulic valve features a 120V AC coil and is ideal for reliable industrial hydraulic system control.
