Product Description
Rosemount 1151GP4E22M3DFD6K14 Pressure Transmitter
The Rosemount 1151GP4E22M3DFD6K14 is a highly reliable Alphaline gauge pressure transmitter designed for precise measurement in demanding industrial environments. Featuring a robust 316 stainless steel construction and silicone fill fluid, this Range 4 transmitter ensures long-lasting performance and accuracy. It delivers a standard industry 4-20 mA output signal and supports a calibration range of -500 to 2000 mm H2O, making it ideal for a wide variety of process control applications. With convenient zero and span adjustments located under the label and a maximum working pressure of 0.0373 MPa, the Rosemount 1151 series continues to be a trusted choice for dependable and accurate pressure monitoring.
Technical Specifications:
- Brand: Rosemount
- Model: 1151GP4E22M3DFD6K14
- Transmitter Type: Alphaline Gauge Pressure (GP)
- Calibration Range: -500 to 2000 mm H2O
- Output Signal: 4-20 mA
- Maximum Supply Voltage: 45 VDC
- Maximum Working Pressure: 0.0373 MPa
- Sensor Range: Range 4
- Wetted Materials: 316 Stainless Steel (SST)
- Fill Fluid: Silicone (SIL)
Rosemount 1151GP4E22M3DFD6K14 Pressure Transmitter
Shop the Rosemount 1151GP4E22M3DFD6K14 Alphaline Gauge Pressure Transmitter. Engineered for industrial durability with 316 SST construction, it features a -500 to 2000 mm H2O calibration range, reliable 4-20 mA output, and 0.0373 MPa maximum working pressure. Ideal for accurate process control and monitoring.
