Product Description

ROSEMOUNT S46MC-C LC-ELS-01

The Rosemount S46MC-C LC-ELS-01 is a high-performance combination pH/ORP sensor engineered for reliability and durability in demanding industrial process applications. Constructed with a robust Liquid Crystal Polymer (LCP) body, this sensor offers exceptional resistance to harsh chemicals and high temperatures. Its advanced design ensures accurate and stable measurements, making it ideal for use in chemical processing, water treatment, and other challenging environments. The S46MC-C is designed for seamless integration with a wide range of Rosemount analytical transmitters, providing a complete and dependable measurement solution.

Technical Specifications:

  • Measurement Range: 0 to 14 pH / -1500 to +1500 mV (ORP)

  • Operating Temperature: -10 to 100 °C (14 to 212 °F)

  • Maximum Pressure: 7.9 barg (100 psig) at 100 °C (212 °F)

  • Wetted Materials: Liquid Crystal Polymer (LCP), PTFE, Glass, Titanium

ROSEMOUNT S46MC-C LC-ELS-01 Description

ROSEMOUNT S46MC-C LC-ELS-01

Discover the Rosemount S46MC-C LC-ELS-01, a durable combination pH/ORP sensor with a Liquid Crystal Polymer body, designed for precise and reliable measurements in harsh industrial chemical applications.
