Product Description
SIEMENS 1FK7022-5AK71-1LB0 Servo Motor
The SIEMENS 1FK7022-5AK71-1LB0 is a high-performance 3-phase SIMOTICS S synchronous servo motor engineered for highly dynamic and precise motion control applications. Manufactured in Germany, this compact motor delivers a rated torque of 0.60 Nm at 6,000 RPM, with a maximum speed capability of up to 10,000 RPM. It comes equipped with an advanced AM20DQ M42 absolute encoder for accurate positioning and an integrated 24VDC holding brake (8.2W) for enhanced operational safety. Built to withstand demanding industrial environments, it features an IP64 protection rating and thermal class 155 (F). Fully certified to cULus, CE, EAC, and EN 60034 standards, this servo motor ensures reliable, globally compliant operation for your automation systems.
Technical Specifications:
- Brand: SIEMENS
- Model: 1FK7022-5AK71-1LB0
- Motor Type: 3-Phase Synchronous Servo Motor
- Static Torque (M₀): 0.85 Nm
- Stall Current (I₀): 1.8 A
- Rated Torque (M_N): 0.60 Nm
- Rated Current (I_N): 1.4 A
- Rated Speed (n_N): 6000 /min
- Maximum Speed (n_max): 10000 /min
- Input Voltage (U_IN): 174 V
- Encoder Type: AM20DQ M42
- Holding Brake: 24VDC, 8.2W
- Degree of Protection: IP64
- Thermal Class: 155 (F)
- Weight: 2 kg
- Certifications: cULus, EN 60034 (H), EAC, CE
- Country of Origin: Germany
SIEMENS 1FK7022-5AK71-1LB0 Servo Motor
Shop the SIEMENS 1FK7022-5AK71-1LB0 3-phase synchronous servo motor. Featuring 0.60 Nm rated torque, 6000 RPM, AM20DQ absolute encoder, 24VDC brake, and IP64 protection, this compact motor delivers premium precision and reliability for industrial automation.
