Product Description
Siemens 6ES7288-3AQ02-0AA0
The Siemens 6ES7288-3AQ02-0AA0 is a Signal Board (SB AQ02) designed for the SIMATIC S7-200 SMART series of programmable logic controllers. This compact module expands the functionality of the S7-200 SMART CPU by providing two analog outputs. It allows for precise control of actuators or devices that require analog voltage or current signals, such as proportional valves, drives, or analog indicators. The SB AQ02 easily integrates with the S7-200 SMART CPU, offering a cost-effective solution for applications requiring analog output capabilities.
Technical Specifications:
- Product Type: Signal Board Analog Output SB AQ02
- Compatible PLC System: SIMATIC S7-200 SMART
- Number of analog outputs: 2
- Output range, voltage: +/-10 V
- Output range, current: 0 to 20 mA
- Resolution for voltage output: 11 bit
- Resolution for current output: 12 bit
- Isolation: No (between analog outputs and CPU)
- Power supply: From CPU backplane bus
- Dimensions (W x H x D): 38 mm x 62 mm x 21 mm
- Weight: Approx. 40 g
- Ambient temperature during operation (horizontal installation): 0 °C to 55 °C
- Ambient temperature during operation (vertical installation): 0 °C to 45 °C
Siemens 6ES7288-3AQ02-0AA0
Model：Siemens 6ES7288-3AQ02-0AA0
