Product Description
VICKERS DG4V-3-OA-M-U-H7-69-EN124
The Vickers DG4V-3-OA-M-U-H7-69-EN124 is a high-performance, direct-operated solenoid directional control valve from Eaton’s renowned DG4V series. Designed for industrial hydraulic applications, this valve provides precise and reliable control of fluid direction. It features a standard D03 (NG6) mounting interface for easy integration into new and existing systems. The ‘OA’ spool configuration ensures all ports (P, A, B, T) are blocked in the neutral, spring-centered position, preventing actuator drift. This model is equipped with a solenoid monitor switch for enhanced safety and system feedback, confirming the solenoid’s operational state. Its robust construction ensures long service life and consistent performance even in demanding environments.
Technical Specifications:
- Valve Type: Direct solenoid operated directional control valve
- Mounting Interface: ISO 4401-03, NFPA D03, NG6
- Spool Type: ‘OA’ – 3 Position, Spring Centered, All ports blocked
- Solenoid Voltage: 115V AC 60Hz / 110V AC 50Hz (Code H7)
- Electrical Connection: DIN 43650 (ISO 4400) connector
- Maximum Operating Pressure: 350 bar (5075 psi)
- Features: Solenoid monitor switch (Code M)
VICKERS DG4V-3-OA-M-U-H7-69-EN124
Buy the Vickers DG4V-3-OA-M-U-H7-69-EN124 directional control valve. This D03 / NG6 solenoid valve features a 115V AC coil, all-ports-blocked spool, and a solenoid monitor switch for reliable hydraulic control.
