Product Description
AIRTEC M-22-510-HN Solenoid Valve
The AIRTEC M-22-510-HN is a high-performance 5/2 way single solenoid valve designed for reliable pneumatic control in industrial automation applications. Part of the M-22 series, this valve features a compact design with G1/8″ ports, offering a robust solution for controlling double-acting pneumatic cylinders or actuators. It operates via an electrical signal to the solenoid, shifting the valve spool, and returns to its initial position via a mechanical spring when the signal is removed. Known for its durability and high flow rate relative to its size, it’s a popular choice for demanding environments. Note: The ‘HN’ suffix typically specifies coil and connector details; please verify the exact coil voltage and connector type required for your application.
Technical Specifications:
- Valve Function: 5/2 Way Single Solenoid Valve
- Actuation: Solenoid / Mechanical Spring Return
- Port Size: G1/8″
- Nominal Flow Rate (Qn): Approx. 500 Nl/min (at 6 bar, Δp=1 bar)
- Operating Pressure Range (Solenoid Pilot): 2 – 10 bar (dependent on coil)
- Control Pressure Range (External Pilot, if applicable): -0.95 – 10 bar
- Orifice Size: 5 mm
- Ambient Temperature Range: -10°C to +70°C (depending on coil/seals)
- Medium: Filtered (50 µm), lubricated or non-lubricated compressed air
- Body Material: Anodized Aluminium
- Seals Material: NBR (Nitrile Rubber)
- Coil Compatibility: Requires separate AIRTEC coil (e.g., Type MI-05) and connector (e.g., Type K-22-HN) – The ‘HN’ suffix often relates to these components.
AIRTEC M-22-510-HN
Model:AIRTEC M-22-510-HN
| Brand | AIRTEC |
|---|---|
| Model | M-22-510-HN |
| Part No. | AIRTEC M-22-510-HN |
| Category | Hydraulic valves |
| Link | https://www.echuan-hydraulic.com/product/airtec-m-22-510-hn |
