Product Description
Balluff BES0433
The Balluff BES0433 (BES M18MI-POC80B-S04G) is a high-performance inductive proximity sensor designed for reliable, non-contact detection of metallic objects in industrial automation environments. Encased in a rugged, nickel-plated brass M18 housing, this sensor offers a standard 8 mm sensing range with a flush-mountable design. Its PNP NO (Normally Open) output and standard M12 connector ensure easy integration into existing control systems. With an IP68 protection rating, the BES0433 is built to withstand harsh conditions, including dust and water ingress, making it an ideal choice for applications in machine tools, packaging, and material handling.
Technical Specifications:
- Model: BES M18MI-POC80B-S04G
- Sensing Distance (Sn): 8 mm
- Output Type: PNP Normally Open (NO)
- Housing: M18x1, Brass, nickel-plated
- Mounting: Flush mountable
- Connection: M12x1 connector, 4-pin
- Operating Voltage: 10…30 V DC
- IP Rating: IP68

Balluff BES0433
Balluff BES0433 M18 inductive sensor with an 8mm sensing range, PNP NO output, and M12 connector. A robust and reliable solution for metal object detection in industrial automation.
