Product Description
Danfoss MBC5100 061B110366 4241-2DB04
The Danfoss MBC 5100 is a compact, block-type pressure switch designed for reliable performance in harsh industrial and marine environments. This model, part number 061B110366, is engineered to withstand severe conditions, offering high vibration resistance and robust construction. It is particularly suitable for alarm and regulation systems in applications where space and reliability are critical. The MBC 5100 features a fixed but low differential pressure, ensuring accurate monitoring of critical pressures. With all major ship approvals, it is an ideal choice for marine applications, offshore installations, and demanding industrial machinery.
Technical Specifications:
- Model: MBC 5100, 4241-2DB04
- Part Number: 061B110366
- Pressure Range: 2 to 20 bar
- Differential Pressure: 0.8 to 4.0 bar (Adjustable)
- Contact Function: SPDT (Single Pole Double Throw)
- Pressure Connection: G 1/4 A (ISO 228/1)
- Enclosure Rating: IP65
- Approvals: All major marine approvals including ABS, BV, CCS, DNV, GL, KR, LR, NKK, RINA, RMRS

Danfoss MBC5100 061B110366 4241-2DB04
Buy the Danfoss MBC 5100 pressure switch, part number 061B110366. This robust, marine-approved block-type switch operates in a 2-20 bar range and is ideal for harsh industrial and offshore applications requiring high reliability.
