Product Description
Danfoss MBS5100 060N1035
The Danfoss MBS 5100 is a high-performance, block-type pressure transmitter designed for reliable pressure measurement in harsh industrial and marine environments. This model, 060N1035, is engineered to withstand severe conditions including cavitation, liquid hammer, and significant pressure peaks. Its robust construction, excellent vibration stability, and a high degree of EMI protection make it ideal for demanding applications. With a comprehensive range of ship approvals, the MBS 5100 ensures compliance and reliability for marine systems, providing accurate and stable output for precise monitoring and control.
Technical Specifications:
- Pressure Range: 0 – 16 bar (Gauge)
- Output Signal: 4 – 20 mA
- Pressure Connection: G 1/4 A Standard (ISO 228-1)
- Electrical Connection: Pg 9, EN 175301-803-A (DIN Plug)
- Accuracy (Typ.): ±0.5 % FS
- Approvals: Ship approved (LR, DNV, GL, RINA, ABS, BV, NKK, PRS, MRS)
Danfoss MBS5100 060N1035
Order the Danfoss MBS 5100 060N1035 pressure transmitter. This ship-approved sensor features a 0-16 bar range, 4-20 mA output, and G 1/4 connection for reliable performance in demanding marine and industrial applications.
