Product Description
Danfoss MBS5100 060N1219
The Danfoss MBS 5100 is a high-performance, block-type pressure transmitter engineered for severe industrial and marine environments. This model is specifically designed to deliver reliable and accurate pressure measurements even under extreme conditions, including heavy vibrations, temperature fluctuations, and aggressive media. With a robust, compact design and a comprehensive range of marine approvals, the MBS 5100 is the ideal choice for demanding applications such as ship engines, pumps, compressors, and hydraulic systems, ensuring operational safety and efficiency.
Technical Specifications:
- Pressure Range: 0 – 250 bar
- Output Signal: 4 – 20 mA
- Pressure Connection: G 1/4 A (ISO 228-1)
- Electrical Connection: Plug EN 175301-803-A
- Supply Voltage: 10 – 32 V DC
- Marine Approvals: LR, DNV, GL, RMRS, ABS, BV, NKK, CCS, KRS
Danfoss MBS5100 060N1219
Buy the Danfoss MBS5100 060N1219 block-type pressure transmitter. This ship-approved sensor features a 0-250 bar range, 4-20 mA output, and a G 1/4 connection, ideal for heavy-duty marine and hydraulic applications.
| Brand | DANFOSS |
|---|---|
| Model | MBS5100 060N1219 |
| Category | Electrical |
| Link | https://www.echuan-hydraulic.com/product/danfoss-mbs5100-060n1219 |
