Product Description
Norgren VCB22D511A-AD219J
The Norgren VCB22D511A-AD219J is a highly integrated vacuum control block from Norgren’s VCB22 series. Engineered for compactness and efficiency, it consolidates essential vacuum system components such as a vacuum ejector, solenoid control valves for suction and blow-off, and potentially a silencer, into a single manifold-ready unit. This model is specified with a 24V DC electrical interface featuring an M8 connector with cable, designed for robust performance in industrial automation, robotics, and material handling applications where reliable vacuum control is critical.
Technical Specifications:
- Product Type: Compact Vacuum Control Block
- Manufacturer: Norgren
- Series: VCB22
- Model Identifier (Pneumatic Configuration): VCB22D511A (this part of the model number defines specific features such as ejector nozzle size, valve functions, presence/type of vacuum switch, and silencer type)
- Operating Medium: Filtered compressed air (consult Norgren datasheet for specific air quality requirements)
- Vacuum Generation: Integrated ejector principle
- Control Functions: Solenoid-actuated suction control and blow-off control
- Solenoid Voltage: 24V DC (as per ‘AD2’ in the part number)
- Solenoid Power Consumption: Approximately 1.9W per solenoid (typical for ‘AD2’ specification)
- Solenoid Electrical Connection: M8x1, 3-pin female connector, straight, with LED, protective circuit (varistor), and 2-meter PUR moulded cable (Norgren electrical code AD219J)
- Typical Applications: Automated pick and place, packaging machinery, robotics, general industrial vacuum systems
- Mounting: Designed for manifold mounting or individual installation
Norgren VCB22D511A-AD219J
Model：Norgren VCB22D511A-AD219J
| Brand | Norgren |
|---|---|
| Model | VCB22D511A-AD219J |
| Part No. | Norgren VCB22D511A-AD219J |
| Category | Hydraulic valves |
| Link | https://www.echuan-hydraulic.com/product/norgren-vcb22d511a-ad219j |
