Product Description
Phoenix IL PB BK DP/V1 2718688
The Phoenix Contact IL PB BK DP/V1 2718688 is a high-performance bus coupler designed for the Inline automation system. It serves as the crucial link between an Inline I/O station and a PROFIBUS network, enabling seamless data exchange and control. This module supports the PROFIBUS DP/V1 protocol and automatically detects transmission speeds from 9.6 kbps up to 12 Mbps. It allows for the connection of up to 63 Inline terminals, offering extensive I/O capabilities for complex industrial applications. Its compact design and DIN rail mounting make for easy installation and integration into existing control cabinets.
Technical Specifications:
- Product Type: Bus Coupler
- Communication Protocol: PROFIBUS DP/V1
- Transmission Speed: 9.6 kbps to 12 Mbps (automatic detection)
- Interface: PROFIBUS DP via 9-pos. D-SUB female connector
- Supply Voltage: 24 V DC
- Degree of Protection: IP20
- Ambient Temperature (operation): -25 °C to 55 °C
Phoenix IL PB BK DP/V1 2718688
Purchase the Phoenix Contact IL PB BK DP/V1 2718688 PROFIBUS bus coupler. This module provides a reliable interface for connecting Inline I/O stations to a PROFIBUS DP network, supporting speeds up to 12 Mbps for efficient industrial automation.
