Product Description
Pilz PNOZ 11 75110 Safety Relay
The Pilz PNOZ 11 75110 (Ident.-Nr. 774083) is a premium industrial safety relay module engineered for the reliable monitoring of emergency stop buttons and safety gates. Manufactured in Germany, this dual-channel safety relay ensures maximum protection for personnel and machinery by safely interrupting control circuits when hazardous conditions are detected. It features a flexible power supply input of 110 VAC or 24 VDC and comes equipped with multiple safety contacts capable of handling demanding industrial loads. With easy-to-wire screw terminals and comprehensive compliance including CE and cULus certifications, the PNOZ 11 is an essential component for maintaining rigorous safety standards in automated environments.
Technical Specifications:
- Brand: Pilz
- Model: PNOZ 11 75110 (Ident.-Nr. 774083)
- Power Supply: 110 VAC (7VA) / 24 VDC (4W)
- Contact Rating (AC15): 230V 5.0A
- Contact Rating (DC13): 24V 7.0A
- Contact Rating (AC1): 250V 8.0A / 400V 5.0A
- Terminal Type: Screw terminals (S11, S12, Y1, Y2, etc.)
- Certifications: CE, cULus LISTED (IND.CONT.EQ. US 4D47)
- Country of Origin: Made in Germany
Pilz PNOZ 11 75110 Safety Relay
Shop the Pilz PNOZ 11 75110 (774083) Safety Relay for dependable emergency stop and safety gate monitoring. This dual-channel relay features 110VAC/24VDC power options, high-capacity contacts, and CE/cULus approvals for optimal industrial automation machine safety.
| Brand | Pilz |
|---|---|
| Model | PNOZ 11 75110 |
| Part No. | 1029372644028 |
| Category | Electrical |
| Link | https://www.echuan-hydraulic.com/product/pilz-pnoz-11-75110-safety-relay |
