Product Description
Rexroth ZDB10VP2-41/100V R900409959
The Rexroth ZDB10VP2-41/100V is a pilot-operated pressure relief valve configured as a sandwich plate valve. It is designed to limit the pressure in two ports (typically A and B) within a hydraulic system. This valve mounts between a directional control valve and its subplate or manifold, conforming to the ISO 4401-05 (NG10 / CETOP 5) standard. The ZDB10VP2 type includes integrated check valves allowing free flow from the actuator ports (A1, B1) back to the directional valve ports (A2, B2). This specific model features FKM seals (Viton) and has a maximum pressure setting of 100 bar, adjustable via a rotary knob.
Technical Specifications:
- Valve Type: Pilot operated pressure relief valve
- Design: Sandwich plate valve
- Size: NG10 / CETOP 5 / ISO 4401-05
- Mounting Pattern: ISO 4401-05-04-0-05
- Function: Pressure limitation in ports A and B with check valve for free return flow (A1->A2, B1->B2)
- Maximum Operating Pressure (System): 315 bar (4568 psi)
- Maximum Flow: 100 l/min (26.4 GPM)
- Pressure Setting Range: Up to 100 bar (1450 psi)
- Adjustment Type: Rotary knob (standard)
- Hydraulic Fluid Compatibility: Mineral oils (HL, HLP) DIN 51524; check compatibility for others
- Seal Material: FKM (Viton)
- Fluid Temperature Range: -20°C to +80°C (-4°F to +176°F) with FKM seals
- Material Number: R900409959
Rexroth ZDB10VP2-41/100V R900409959
Model:Rexroth ZDB10VP2-41/100V R900409959
| Brand | Rexroth |
|---|---|
| Model | ZDB10VP2-41/100V R900409959 |
| Part No. | Rexroth ZDB10VP2-41/100V R900409959 |
| Category | Hydraulic valves |
| Link | https://www.echuan-hydraulic.com/product/rexroth-zdb10vp2-41-100v-r900409959 |
