Product Description
UNIVER AM-5503 Solenoid Valve
The UNIVER AM-5503 is a 5/2 way single solenoid valve designed for pneumatic control systems. It features G1/4″ port connections and operates using solenoid actuation with a spring return mechanism (monostable). This valve is part of the Univer AM series, known for its reliability in controlling double-acting pneumatic cylinders and other actuators in industrial automation. It is constructed with an aluminium body and offers a robust solution for managing compressed air flow.
Technical Specifications:
- Function: 5/2 Way Monostable (Single Solenoid / Spring Return)
- Series: AM
- Port Size: G1/4″
- Actuation Type: Indirect Solenoid
- Operating Pressure: 1.5 ÷ 10 bar
- Nominal Flow Rate (at 6 bar, ΔP 1 bar): 1250 Nl/min
- Nominal Orifice Diameter: 8 mm
- Fluid: Filtered compressed air (50 µm), lubricated or non-lubricated
- Operating Temperature: -10°C to +60°C
- Body Material: Aluminium
- Spool Material: Aluminium
- Seals: NBR
- Manual Override: Standard Push Type
- Note: Solenoid coil and connector typically ordered separately.
UNIVER AM-5503
Model:UNIVER AM-5503
| Brand | Univer |
|---|---|
| Model | AM-5503 |
| Part No. | UNIVER AM-5503 |
| Category | Hydraulic valves |
| Link | https://www.echuan-hydraulic.com/product/univer-am-5503 |
